Cosmic® Solar Charger
Cosmic® Solar Charger
Cosmic® Solar Charger is a versatile charger that can be used to charge a variety of devices, including smartphones, tablets, laptops, cameras, power banks, and other electronic devices. It is also ideal for use in remote locations where access to electricity is limited. Built with high-quality components and designed to last, Cosmic® Solar Charger is highly efficient and supports wide voltage range.
Features
- Maximum Power Point Tracking (MPPT)
- High efficiency
- Wide voltage range (12V, 24V, 36V and 48V)
- Longer Battery Life
- Multiple Safety Protections
- Easy to use
Description
Cosmic® Solar Charger is a micro controller-based high-efficiency MPPT (Maximum Power Point Tracking) charger for solar panels from 1Kva to 100Kva. It uses a unique algorithm to scan the circuit and find the point at which maximum power is delivered. This allows the charger to extract more power from solar panels than conventional chargers. To useCosmic® Solar Charger, simply connect the solar panels and the devices to the charger and start charging. The charger will automatically detect the voltage of the solar panels and adjust its output accordingly. The charger has a built-in LED indicator to show the charging status. It is also equipped with a number of protections to keep devices safe, including reverse polarity protection, over – voltage protection, and over – current protection.
Specification
| SPECIFICATIONS | MPPT-0.3 to MPPT-3.0 | MPPT-5.0 to MPPT-30.0 |
|---|---|---|
| Panel voltage range | 10 to 22V, 20 to 44V, 30 to 66V, 40to 88V (With respect to 12V, 24V, 36V, 48V models) DC |
96V – 768V DC |
| PWm frequency | 20KHz | |
| Power stage topology | Buck converter | Multiphase Invertleaved DC – DC Converter |
| Switching elemeny | MOSFET | IGBT |
| Current sensing | Dropless current sensing using Hall effect CT | |
| charging current | 10A to 80A | |
| Power conversion efficency |
>95% at full rated current | |
| Protections | PV Transient voltage surge, PV reverse polarity, High battery voltage, Low battery voltage. Over temperature, Overcharging |
|
| Cooling | Automatic cooling fan | |
| Temp. compensation range |
-5 to 7mV / celsius ( optional) | |
| COMMUNCIATION INTERFACE |
RS232 Communciation ( optional) | |
| Temperature | 0-600C | |
| Relative Humidity | 0 – 95% (non-condensing) | |
Frequently Ask Question Now.
What is Cosmic® Solar Charger?
Cosmic® Solar Charger is a micro controller-based MPPT (Maximum Power Point Tracking) charger for solar panels from 1Kva to 100Kva. It uses a unique algorithm to scan the impedance of the circuit from maximum to minimum and find the point at which maximum power is delivered. This allows the charger to extract up to 30% more power from your solar panels than conventional chargers.
What are the benefits of using Cosmic® Solar Charger?
Cosmic® Solar Charger offers a number of benefits, including:
- Higher efficiency (extracts up to 30% more power from solar panels than conventional chargers)
- Longer battery life
- Reduced energy costs
- Environmentally friendly
What are the features of the Cosmic® Solar Charger?
The Cosmic® Solar Charger is a high-quality solar charger that offers a number of features, including:
- Maximum Power Point Tracking (MPPT): MPPT technology ensures that you get the most power out of your solar panels, even in low-light conditions.
- High efficiency: The Cosmic® Solar Charger is highly efficient, converting up to 95% of the solar energy it receives into electricity.
- Wide voltage range: The Cosmic® Solar Charger can be used with a variety of solar panels, including 12V, 24V, 36V, and 48V panels.
- Multiple protections: The Cosmic® Solar Charger is equipped with a number of protections to keep your devices safe, including reverse polarity protection, overvoltage protection, and overcurrent protection.
- Easy to use: The Cosmic® Solar Charger is very easy to use. Simply connect your solar panels and your devices to the charger and start charging.
What types of devices can I charge with the Cosmic® Solar Charger?
The Cosmic® Solar Charger can be used to charge a variety of devices, including:
- Smartphones
- Tablets
- Laptops
- Cameras
- Power banks
- Other electronic devices
My Cosmic® Solar Charger is not working. What should I do?
If your Cosmic® Solar Charger is not working, there are a few things you can check:
- Make sure that the solar panels are connected to the charger and the charger is connected to the battery.
- Make sure that the solar panels are in a sunny location.
- Check the connections to make sure they are secure.
- Try restarting the charger.
If you are still having problems, please contact Cosmic® Micro Systems for assistance.
