Lift UPS


Lift UPS Power Generating System with MPPT is Double Conversion with Load Sharing Technology. This is one of the advanced technology in the market to utilize 100% of Solar PV Generated power by enhancing Solar Power through MPPT Load Sharing and current control technology which can be used for sensitive, sophisticated and industrial loads.



The output load is completely isolated from input by using Double conversion technology and also our Solar UPS Out power is constant for 24/7 without any fluctuation.



The Solar power is utilized maximum level even during cloudy season. The priority is always for Solar Power. Solar Power and Electric Board(EB) Power will be paralleled and will work together but always priority is for the Solar Power. After utilizing Solar Power still if load required more than Solar generated power. Our Solar UPS Smart Dual Sharing technology will allow EB Power to feed the power to Inverter Input. So Output load is protected with Uninterrupted Clean Power.

myimg
  • DSP based control guarantees high reliability.
  • Pure Sine Wave output.
  • 30% More energy is harvested by using MPPT solar charger.
  • Auto opriority logic in the charger for both mains and solar inputs.
  • If the load is less than 5W, the inverter automatically switches to sleep mode to save power.
  • Compact and light weight.
  • User friendly installation.
  • High efficiency and extended backup time.
  • Normal and Computer mode.
  • Noiseless operation of fans, lamps and Home.
  • Liquid crystal display.

During Day time, Cosmic Lift UPS will work as Solar Power generating System which will generate the power by using Sunlight through Solar Photo Voltaic Modules priority will be for Solar Energy. When Solar Power is available our Solar Hybrid System will charge the battery completely through Solar Charger. The MPPT Charger will enhance the Solar power by 15 to 30% Once Battery is fully charged based on availability of SPU Power. It will supply the Solar Power to output load without any interruption by switching of the EB Power to ensuring 100% utilization of Solar Power so you need not depend on EB Power. When Sunlight power is not available this will reconnect the EB Power to ensuring the uninterrupted power supply. Even during power cut, in the night the stored Solar Power from the Batteries can be utilized as backup power.

 DESCRIPTION

 SOLAR SINEWAVE UPS TECHNICAL  SPECIFICATION

 TECHNOLOGY

 3 Phase Line Interactive, IGBT, DSP and PWM based

 MODEL

 CLU 06 to CLU 250

 CAPACITY

 6 KVA to 150 KVA

 AC INPUT Voltage

 415V AC +15% or -20%, 50Hz +/-6Hz

 100V - 300V AC for lighting

 AC OUTPUT Voltage

 < 400/415V AC +/- 1%, 3Phase 4 Wire(on  Battery Mode)

 Wave Form

 Pure Sinewave

 Output Power factor
 and THD

 0.8 to 1Lagging, <3% with Linear load

 Cooling

 > Forced Air

 Protection

 Input Under and Over Voltage, Single Phase,

 Reverse Phase, Output Under and Over Voltage,

 Overload Short Circuit,
 battery low and Over Charge with Alarm

 Communication

 RS 232 and SMS Alerts(Optional)

 Application

 Elevators, Lifts, Motors, Lightings
 or any kond of three phase load
